What is a Concrete Block Making Machine?
A Concrete Block machine is primarily used as a building block which is used in the construction of walls. A Concrete Block is one of several precast concrete products used in construction. The term precast refers to the fact that the blocks are formed and hardened before they are brought to the job site. The production of Concrete Blocks consists of four basic processes: mixing, molding, curing, and cubing. This Concrete Block Making Machines is maintenance free and heavy duty, as being the leading Concrete Block machine manufacturer we recommend you our best machines.
We are amongst the top and premium Fully Automatic Concrete Block Machine Manufacturers & Suppliers in Maharashtra. This Concrete Block Making Machine is manufactured using supreme quality material and latest technology resulting in durable and longer functional life. This Fully Automatic Concrete Block Making Machine is widely appreciated due to customized solutions for our clientele. Thanks to a flawless finish, sturdy construction and accurate functioning, as the leading Fully Automatic Concrete Block Machine manufacturer we are very much appreciated by our clientele over the others. Owing to an affordable price, this Fully Automatic Concrete Block Making Machine is widely popular in the market.
Enquire Now
| Model No. PHM- 06 Plant | Machine Details |
| Hydraulic Motor | 10 HP |
| Vibro Motor | 4 HP |
| Pallet Size | 600 x 570 x 6 mm/675 x 600 x 6 mm |
| Pallets Material | Steel |
| Panel Board | PLC |
| Heaters In Mould | Yes |
| Agitator In Trolley | Yes |
| Cycle Time | 12 to 17 seconds |
| Model No. PHM- 06 Plant | Pan Mixer Details |
| Capacity | 500/800/1200 kg |
| Bucket Capacity | 500/800/1200 kg |
| Main Hydraulic Motor | 15/25/40 HP |
| Bucket Lifting Hydraulic Motor | 5 HP |
| Water Motor | 0.5 HP |
| Bins For Material | 3 |
| Load Cell 3 Nos | 1.5 Ton Capacity |
| Digital Display For Material & Water | Yes |
| Water Flow Control | Automatic |
| Model No. PHM- 06 Plant | Conveyer Details |
| Hydraulic Motor | 5 HP |
| Length | 7.5 meters |
| Width Of Belt | 450 mm |
| Model No. PHM- 06 Plant | Receiving Carriage Details |
| Hydraulic Motor | 1 HP |
| Length | 2.5 meters |
| Model No. PHM- 06 Plant | Stacker Details |
| Hydraulic Motor | 3 HP |
| Length | 2 meters |
| Width | 1 meter |
